CEMBRE - Z6 - SINGLE-POLE TERMINAL BLOCKS, WITH INDIRECT CLAMPING, NOMINAL SECTION 6MMQ

Categories > Electrical connectors > Terminal blocks and distribution blocks > Indirect clamping terminal blocks >

Z6

SINGLE-POLE TERMINAL BLOCKS, WITH INDIRECT CLAMPING, NOMINAL SECTION 6MMQ

Gallery

Z6

SINGLE-POLE TERMINAL BLOCKS, WITH INDIRECT CLAMPING, NOMINAL SECTION 6MMQ

Documentation

Instructions (pdf)

Certifications & approvals

CE
RINA
UKCA

Features

Technical information
Material composition and treatments
Weight and dimensions
Logistic
Classification and data ordering

Maximum operating temperature

85 °C

Ingress Protection

IP20

Markings found

factory mark; cembre catalogue number; CE mark; IMQ mark; nominal section; nominal voltage; max operating temperature

Geometry of the clamping element

slotted screw

Reference standard

EN 60998-1; EN 60998-2-1

Easy insertion input

Yes

Self-extinguishing fire class according to UL 94

Torque of the clamping element

0.8 Nm

Screw pitch

M3x7.5

Captive screw

Yes

Clamping type

indiretto

Operating current

60 A

Short-circuit current

1 kA

Short circuit current time

1000 ms

Suitable for earth connections

Minimum thickness of the surface coating of the conducting body

3 µm

Halogen free

Clamping element material

electrolytically zinc plated tempered steel

Insulated body material

polycarbonate

Cage material

electrolytically zinc plated tempered steel

Surface treatment of the cage

electrolytically zinc plating tempered

Plate material

copper

Surface treatment of the clamping element

electrolytically zinc plating tempered

Surface treatment of the plate

tin plating

Minimum thickness of the plate surface coating

3 µm

Insulated body color

trasparent

Lloyd's Register of Shipping mark

False

Range of cable cross section

1 ÷ 6 mm²

Cable stripping length

12 mm

Nominal voltage

450 V

Number of poles

Way connection capacity

1x6 mm² R/F; 1x4 mm² R/F; 1÷2x2.5 mm² R/F; 1÷2x1.5 mm² R/F; 1÷4x1 mm² R/F

IMQ mark

False

Type of packaging

; box

Customs code

85369010

ETIM Class 7

Single- and multi-pole terminal strip [EC001284]

tipo	Attachment for DIN rail	DIN rail attachment material	Italian naval register mark	Gross weight [g]	Number of ways	Height [mm]	Width [mm]	Length [mm]	Unit in standard packaging [pce]	Minimum order quantity [pce]
Z6-3	No		Yes	15,000	3	28	23	23	30	30
Z6-3D	Yes	acciaio	Yes	21,600	3	28	23	23	10	10
Z6-5	No		Yes	23,200	5	28	23	35	20	20
Z6-5D	Yes	acciaio	Yes	29,600	5	28	23	35	10	10
Z6-10	No		False	45,200	10	28.5	43	35	10	10
Z6-10D	Yes	acciaio	False	50,667	10	28.5	43	35	15	15
Z6-6	No		False	28,933	6	28	43	23	15	15
Z6-6D	Yes	acciaio	False	35,000	6	28	43	23	10	10
